Product information:
| Input/Output Power Rating | 3.7kw/7.4kw/11kw/22kw |
|---|---|
| Current | 16A/32A/16A/32A |
| Votage | 230V±15%/230V±15%/400V±15%/400V±15% |
| Network | type 1phase 3 Wire – L1, N, PE/3 phase 5 Wire – L1, L2, L3, N, PE |
| Protection | Overcurrent, overvoltage, undervoltage, integrated surge protection |
General Features :
| IP rating | IP54 |
|---|---|
| Operating Temperature Range | -30℃~+50℃ |
| Storage Temperature Range | -40℃~+70℃ |
| Dimensions | 5m/8m/10m |
| IP Class | IP54 |
| Fire Rating | UL94V-0 |
Certification and Standards:
| Safety and Compliance | IEC 61851-1, EN 50663, EN 50665, IEC/EN62955 |
|---|---|
| Certification | CE (TÜV) |
| Warranty | 36 months, warranty extension possible |
